CHAINWAY

Chainway CP30 Thermal Transfer / Direct Thermal RFID Printer

Write a Review
SKU:
CP30
  • Chainway CP30 Thermal Transfer / Direct Thermal RFID Printer
  • Chainway CP30 Thermal Transfer / Direct Thermal RFID Printer
  • Chainway CP30 Thermal Transfer / Direct Thermal RFID Printer
Call for pricing
Frequently bought together:

Description

The Chainway CP30 stands out as an RFID printer, delivering exceptional printing capabilities that accommodate both thermal and thermal transfer printing methods. Equipped with a user-friendly 3.5-inch LCD touchscreen, versatile communication interfaces, and the ability to automatically detect printheads of varying resolutions, the CP30 ensures precise and rapid printing of a diverse range of RFID tags, barcodes, invoices, and wristbands. It efficiently caters to the printing requirements across various industries.

Features & Benefits:

  • 3.5" LCD Touch Display
  • Maximum Print Speed: 8ips (203dpi) / 6ips (300dpi)
  • Support Multiple Interfaces
  • Automatic Printhead Resolution Identification
  • Thermal Transfer / Direct Thermal

Ordering Options:

  • CP30 8ips (203dpi)
  • CP30 6ips (300dpi)

Accessories:

 Standard:

  • AC Adaptor
  • USB Cable
  • Lable & Ribbon Sample

Optional:

  • Cutter Module
  • Peel-Off Module
  • Wi-fi Module
  • Bluetooth Module
  • External Roll Holder
  • Printer Head



View AllClose

Additional Information

RFID Tag:
UHF RFID, 860-928MHz, EPC C1G2 (ISO18000-6C)
Types:
Continuous Paper, Gap, Black Mark, Punched Hole Label
Width:
1'' (25.4) - 4.65'' (118mm), include the liner
Thickness:
0.002'' (60um) - 0.01'' (250um)
Label Roll Diameter:
5'' (127mm) Max
Core Diameter:
0.5'' (12.7mm), 1'' (25.4mm), 1.5'' (38mm)
Printing Method:
Thermal transfer / Direct thermal
Resolution:
203dpi / 300dpi
Max. Printing Width:
108mm (203dpi) / 106mm (300dpi)
Max. Printing Length:
2,286mm (203dpi) / 1,524mm (300dpi)
Types:
Wax, Wax / Resin, Resin
Width:
1.18'' (30mm) - 4.33'' (110mm)
Length:
984' (300m)
Core Diameter:
1'' (25.4mm)
Operating Temp.:
41℉ (5℃)-104℉ (40℃), humidity 30% to 85% non-condensing
Storage Temp.:
-4℉ (-20℃)-122℉ (50℃), humidity 10%-90% non-condensinng
download data sheet:
https://rfid4ustore.com/content/data_sheet/Chainway%20CP30%20Datasheet%20.pdf
